Product model

RISEN-ESD

Liquid level measurement range

5m,7m,10m,15m

Ultrasonic level meter, clean environment, stable objective surface

Probe blind area

≤300mm～800mm

varies from different measure range and sensor

Accuracy of detectio

0.5%F·S(default)

at25℃,outside two times of the blind area

0.25%F·S(could be customized)

Output signal

4～20mA (three,four-wire)

default 4～20mA three wire

Relay：1,2,3,4

Showing the way

LED display

Working temperature

0～+50℃(default)

-10～+60℃(could be customized)

Work power

AC220V/50Hz

Protection level

Sensor IP65

IP66，IP67，IP68 can be customized

Cable way

Sensor leads 0.5 m, instrument standard plugs
